Эхолот humminbird 300tx инструкция на русском



Руководство по эксплуатации Humminbird 300TX

Руководство по эксплуатации для устройства Humminbird 300TX

Устройство: Humminbird 300TX
Размер: 0,42 MB
Добавлено: 2014-07-03 16:10:11
Количество страниц: 28
Печатать инструкцию

Как пользоваться?

Наша цель — обеспечить Вам самый быстрый доступ к руководству по эксплуатации устройства Humminbird 300TX . Пользуясь просмотром онлайн Вы можете быстро просмотреть содержание и перейти на страницу, на которой найдете решение своей проблемы с Humminbird 300TX .

Для Вашего удобства

Если просмотр руководства Humminbird 300TX непосредственно на этой странице для Вас неудобен, Вы можете воспользоваться двумя возможными решениями:

  • Полноэкранный просмотр -, Чтобы удобно просматривать инструкцию (без скачивания на компьютер) Вы можете использовать режим полноэкранного просмотра. Чтобы запустить просмотр инструкции Humminbird 300TX на полном экране, используйте кнопку Полный экран .
  • Скачивание на компьютер — Вы можете также скачать инструкцию Humminbird 300TX на свой компьютер и сохранить ее в своем архиве. Если ты все же не хотите занимать место на своем устройстве, Вы всегда можете скачать ее из ManualsBase.
Печатная версия

Многие предпочитают читать документы не на экране, а в печатной версии. Опция распечатки инструкции также предусмотрена и Вы можете воспользоваться ею нажав на ссылку, находящуюся выше — Печатать инструкцию . Вам не обязательно печатать всю инструкцию Humminbird 300TX а только некоторые страницы. Берегите бумагу.

Резюме

Ниже Вы найдете заявки которые находятся на очередных страницах инструкции для Humminbird 300TX . Если Вы хотите быстро просмотреть содержимое страниц, которые находятся на очередных страницах инструкции, Вы воспользоваться ими.

Краткое содержание страницы № 1
Краткое содержание страницы № 2

INSTALLATION PREPARATION PARTS SUPPLIED PARTS SUPPLIED Before installing your new Humminbird fishfinder, please ensure the following parts are included in the box: • Fishfinder • Transducer with 20’ (6m) of cable and mounting hardware kit • Mounting system and mounting hardware kit • 6’ (2m) power cable • Publications kit It any of these items is missing, call our Customer Support Hotline. ACCESSORIES Humminbird offers a wide assortment of accessories that complement and

Краткое содержание страницы № 3

INSTALLATION PREPARATION INSTALLATION OVERVIEW Determining How to Mount the Transducer Your Humminbird fishfinder includes a standard transducer. This transducer can be mounted on the transom of the boat or bonded to the inside of a fiberglass hull boat. The transom installation, which is the most widely used, places the transducer on the outside of the boat hull. This technique produces the least signal loss, and provides a way to adjust the transducer after installation. The m

Краткое содержание страницы № 4

INSTALLATION PREPARATION ALTERNATE MOUNTING METHODS ALTERNATE TRANSDUCERS AND MOUNTING METHODS Your Humminbird fishfinder comes with everything necessary for installation and operation on most boats. However, there are several situations which may require a different type of transducer. Inboard boats, wood or metal hulls, and sail boats create unique transducer mounting needs Alternate transducers and mounting methods are detailed below. Portable Mounting The standard transducer

Краткое содержание страницы № 5

INSTALLATION PREPARATION TRANSDUCER EXCHANGE TRANSDUCER EXCHANGE Other transducers are available as replacements for the standard transducer. You may exchange your new and unassembled transducer for another type by returning it to the address listed in Customer Support. Some transducers may have additional cost. Refer to the Accessory catalog or call Customer Support for information. BEGINNING INSTALLATION Now that you have determined the transducer mounting method you can begin

Краткое содержание страницы № 6

INSTALLATION TRANSOM INSTALLATION Do not begin this transducer installation until you read the Installation Preparation in the Operation Guide. This chapter contains information critical to the correct installation of your transducer. Due to the wide variety of boat hulls, only general instructions are presented in the installation guide. Each boat hull represents a unique set of requirements that should be evaluated prior to installation. TRANSOM INSTALLATION Step One — Determi

Краткое содержание страницы № 7

INSTALLATION TRANSOM INSTALLATION • If the propeller(s) is (are) forward of the transom, it may be impossible to find an area clear from turbulence, and a different mounting technique or transducer type should be considered. Step Two — Drill the Mounting Holes 1. Remove the mounting template from the front of the Operations Manual. 2. Hold the template on the transom of the boat in the location where the transducer will be installed (Figure 4). Align the template vertically, ensu

Краткое содержание страницы № 8

INSTALLATION TRANSOM INSTALLATION Step Four — Mount the Transducer to the Transom 1. Apply silicone sealant to the mounting holes drilled into the transom. 2. Align the transducer assembly with the drilled holes in the transom (Figure 8). 3. Use either a flat head screwdriver, a 5/16″ (8mm) hex driver, or a 5/16″ (8mm) socket to mount the assembly. Using the two #10 – 1” (25mm) long slotted hex head screws, mount the transducer assembly to the transom as shown. Do not fully tight

Краткое содержание страницы № 9

INSTALLATION TRANSOM INSTALLATION Step Six — Route the Cable There are several ways to route the transducer cable to the to the area where the control head will be installed. The most common procedure routes the cable through the transom into the boat. Inside the boat there is often a channel or conduit used for other wiring that the cable can be routed along. Do not cut or shorten the transducer cable and try not to damage the cable insulation. Route the cable as far as practical

Краткое содержание страницы № 10

INSTALLATION INSIDE THE HULL INSTALLATION INSIDE THE HULL INSTALLATION Inside the hull installation requires the mount system and control head be installed and operational. See Installing the Control Head for instruction on installing the unit. Inside the hull mounting generally produces good results in single thickness fiberglass-hulled boats. Humminbird cannot guarantee depth performance when transmitting and receiving through the hull of the boat since some signal loss occur

Краткое содержание страницы № 11

INSTALLATION INSIDE THE HULL INSTALLATION 3. Power up the Control Head. 4. Run the boat at various speeds and water depths while observing the screen on the Control Head. If the unit functions well at low speeds but begins to skip or miss the bottom at higher speeds, the transducer needs to be moved. If depth performance is required, test the fishfinder in water at the desired depth. Test different locations in the hull until the optimum performance is achieved. Step Three — Perman

Краткое содержание страницы № 12

INSTALLATION CONTROL HEAD INSTALLATION CONTROL HEAD INSTALLATION Step One — Determine Where to Mount Begin the installation by determining where to mount the control head. Consider the following to determine best location: • The cables for power, transducer and temp/speed accessories (if applicable) should be installed first and must reach the mounting location. Extension cables are available. • There are two ways to route the cables to the unit: through a hole in the mountin

Читайте также:  Распайка датчика эхолота фишерман 200
Краткое содержание страницы № 13

INSTALLATION CONTROL HEAD INSTALLATION and one amp fuse (not included) for the protection of the unit (Figure 21). Humminbird is not responsible for over voltage or over current failures. In order to minimize the potential for interference with other marine electronics a separate power source (such as a second battery) may be necessary. Step Three — Drill the Mounting Holes 1. Set the mounting bracket in place on the mounting surface. Mark the four mounting screw locations with

Краткое содержание страницы № 14

INSTALLATION CONTROL HEAD INSTALLATION Step Five — Assembling the Connector Holder 1. Insert the cable connectors into the connector holder. The cable connectors are labeled, and there are corresponding labels on the connector holder (Figure 26). The slots for the connectors are keyed to prevent reverse installation, so do not force the connector into the holder. 2. Carefully pull the excess cable from beneath the — mounting surface so the connector holder aligns with the mountin

Краткое содержание страницы № 15

INSTALLATION TEST THE INSTALLATION TEST THE INSTALLATION Testing should be performed with the boat in the water, however you can initially confirm basic operation with the boat trailered. Press POWER once to turn the unit on. There will be an audible chirp when any button is pressed to confirm the button press. If the unit does not power-up, ensure the unit is fully seated on the mount and that power is available. The first screen provides four options: Start-up, Options, Simulat

Краткое содержание страницы № 16

Using the 300TX Actual depth capability depends on factors such as bottom hardness, water conditions, and transducer installation. Units will typically read to deeper depths in fresh water than in salt water. Simulator Operation The 300TX contains a simulator that allows you to use the unit as if you are on the water. The simulator is invaluable for learning how to operate the 300TX. There are two ways to start the simulator. If the unit is powered off, press and hold the POW

Краткое содержание страницы № 17

What You See On-Screen Your 300TX uses a 128 x 64 matrix FSTN LCD display. This display provides outstanding viewability in all light conditions over a wide range of temperatures. At initial power-up, the 300TX uses settings that were set in the factory. After initial use, the 300TX will remember the settings you enter. There are several elements on-screen that are common to all modes of operation. Temperature/Speed. The initial screen layout takes one of two basic forms

Краткое содержание страницы № 18

Wave action also affects the bottom depiction. The information drawn is a distance measurement, so if the boat is moving up and down over flat bottom, the bottom depiction often appears in regular variations that match wave timing. Structure. Structure is defined as any object physically attached to the bottom. The sonar configuration of the 300TX is optimized to give the most accurate depiction of bottom structure possible. Grass, trees, stumps, wrecks or other debris are accurat

Краткое содержание страницы № 19

species. The signal intensity is “normalized” for depth so that a small fish close to the boat does not appear as a large fish symbol. ID+ adds an additional piece of information to help the user locate fish. On selected fish symbols, the digital depth of the designated fish is drawn to help locate the fish vertically. This is especially helpful in setting bait depths or for downrigger operations. The specific fish symbol indicates the type of sonar beam the fish is detected in.

Краткое содержание страницы № 20

screen indefinitely. Once you release the menu button, the screen will time out. Once a menu times out, it is still considered the active menu. Press MENU to bring up the last menu used. Arrow Keys. The UP ARROW and DOWN ARROW make adjustments to menu functions. On the left side of every menu there are UP ARROW and DOWN ARROW symbols. The symbols indicate which ARROW button has a function in a particular situation. Either one or both ARROW buttons can be used to adjust the menu fu

Источник

Спасибо – Инструкция по эксплуатации Humminbird 300 Серия

Страница 2

Спасибо за то, что выбрали Humminbird® — марку номер 1 в США среди

рыбопоисковых эхолотов! Репутация Humminbird® базируется на

разработке и производстве оборудования высшего класса, действительно

соответствующего стандартам водного оборудования. Ваш прибор сделан

так, что вы не будете иметь с ним проблем даже в самых сложных водных

условиях. Если все же ваш прибор потребует ремонта, хотя это и

маловероятно, мы предлагаем бесплатный сервис на протяжении первого

года покупки и скидки на ремонт по истечению первого года. Более

подробную информацию вы найдете в разделе Гарантийный ремонт. Мы

настоятельно рекомендуем вам внимательно прочесть данное руководство

по установке и эксплуатации для того, чтобы максимально воспользоваться

функциями и приемами вашего эхолота Humminbird®.

Для того, чтобы связаться с центром работы с клиентами звоните 1-800-

633-1468 или через нашу страницу в интернете

Внимание! Данный прибор не может быть использован в качестве навигационного

устройства с целью предотвращения столкновения, посадки на мель, повреждения

лодки или телесных травм. При движении лодки глубина может измениться очень

быстро, и вы можете не успеть среагировать. Всегда работайте с эхолотом на

очень малых скоростях, если предполагаете, что впереди мель или затопленные

Внимание! Разборка и ремонт этого электронного прибора должен производиться

исключительно персоналом уполномоченного сервисного центра. Какя-либо замена

серийного номера или же попытка ремонта основного оборудования или

дополнительного оборудования неуполномоченными лицами, влечет за собой отказ

в гарантийном обслуживании. Работая и/или открывая данный прибор, вы можете

быть подвергнуты воздействию свинца в форме припоя.

Внимание! Все картинки в данном руководстве приведены с экрана 320 x 240

пикселей эхолота 383c Combo. Однако вся информация относится и к другим

эхолотам – 363с Combo, 343c, 323.

DualBeam PLUS™, Fish ID+™, Humminbird®, Humminbird® PC™, RTS®

Window, SmartCast®, WhiteLine®, X-Press™ Menu, Structure ID® и

WeatherSense® являются зарегистрированными торговыми марками

©2005 Humminbird®, Eufaula AL, США. Все права защищены.

Читайте также:  Как найти плотву зимой без эхолота

Источник

Humminbird 300TX User Manual

Before installing your new Humminbird fishfinder, please ensure the following parts are included in the box:

∙ Transducer with 20’ (6m) of cable and mounting hardware kit

∙ Mounting system and mounting hardware kit

∙ 6’ (2m) power cable

It any of these items is missing, call our Customer Support Hotline.

Humminbird offers a wide assortment of accessories that complement and expand the capability of your new fishfinder. These accessories are designed with the same high standards and are backed by the same one-year warranty. The Humminbird Accessory catalog included with your unit contains descriptions of the many accessories available and ordering information. All Humminbird accessories are available through your fullservice Humminbird dealer or factory direct through our number listed in the Customer Support section.

Your Humminbird fishfinder consists of two primary components to install: the control head and the transducer.

The control head contains the sonar transmit and receive circuitry, as well as the user controls and display. It should be installed in a location that provides access to the controls and visibility while in use. The control head mounts on a quick disconnect mounting system that swivels and tilts providing flexibility for viewing from almost anywhere on the boat.

The transducer converts electrical energy from the transmitter into mechanical pulses or sound waves. The transducer also receives the reflected sound waves and converts them back into electrical signals for display on the control head. It should be installed in contact with the surface of the water in an area that has smooth waterflowusually on the transom of the boat. There are several mounting options for the transducer. Review the following section to determine the method that works for you and your boat.

Determining How to Mount the Transducer

Your Humminbird fishfinder includes a standard transducer. This transducer can be mounted on the transom of the boat or bonded to the inside of a fiberglass hull boat.

The transom installation, which is the most widely used, places the transducer on the outside of the boat hull. This technique produces the least signal loss, and provides a way to adjust the transducer after installation. The mounting hardware included is designed to protect both the boat and the transducer should the boat strike debris in the water or when trailering.

As an alternative to transom mounting, it is possible on many fiberglass-hulled boats to glue the transducer on the inside of the boat hull. Since fiberglass has similar sonar characteristics as water, the sonar signal can pass through the boat hull with minimal loss. The hull of the boat must be single layer construction (not double-hulled) Also, any air trapped in the lamination of the fiberglass would prevent the sonar signal from passing through.

Inside the hull installations require no holes be drilled into the boat and through experimentation, high-speed operation

comparable to transom mounting can be achieved. Two-part slow cure epoxy (not included) is required to glue the transducer in place.

ALTERNATE MOUNTING METHODS

ALTERNATE TRANSDUCERS AND MOUNTING METHODS

Your Humminbird fishfinder comes with everything necessary for installation and operation on most boats. However, there are several situations which may require a different type of transducer. Inboard boats, wood or metal hulls, and sail boats create unique transducer mounting needs Alternate transducers and mounting methods are detailed below.

The standard transducer can be adapted for portable installations with a portable mounting kit available from Humminbird. This accessory adapts your transducer to a suction cup mount for temporary installation on the boat hull or other surface.

Trolling Motor Mounting

The standard transducer can also be adapted to mount on most trolling motors using a different accessory kit. This accessory includes a bracket and hose clamp that allows mounting the transducer to the body of most trolling motors.

Thru-hull transducers install through a hole drilled in the hull

of the boat. Larger boats or boats with inboard motors create turbulence that make transom mounting ineffective. Also, hulls that are very thick or are double layered, or made from materials such as wood or metal, (which do not conduct sonar signals) make inside the hull mounting inadvisable.

Thru-hull mounting may require the use of a fairing block to level the transducer with the waterline. Also, since special tools and knowledge may be required to perform this type of installation, it is best to refer to a qualified marine technician.

Other transducers are available as replacements for the standard transducer. You may exchange your new and unassembled transducer for another type by returning it to the address listed in Customer Support. Some transducers may have additional cost. Refer to the Accessory catalog or call Customer Support for information.

Now that you have determined the transducer mounting method you can begin installation of your new Humminbird fishfinder. The installation guide included on the next few pages provides detailed step by step instructions for installation of the control head and transducer. For transom mount transducer installations you will need the mounting template included with your manual.

In addition to the parts included you need the following for installation and operation:

∙ A powered hand drill and various drill bits

∙ Philips and flat-head screwdrivers

∙ A ruler or measuring tape

∙ 12 volt power source (your boat’s battery)

∙ A fuse holder (if you are wiring directly to the boat’s battery)

∙ Silicone sealant (for sealing drilled holes)

∙ 2-part, slow-cure epoxy (for inside the hull transducer installations)

Do not begin this transducer installation until you read the Installation Preparation in the Operation Guide. This chapter contains information critical to the correct installation of your transducer.

Due to the wide variety of boat hulls, only general instructions are presented in the installation guide. Each boat hull represents a unique set of requirements that should be evaluated prior to installation.

Step One — Determine Where to Mount the Transducer

Begin the transducer installation by determining where on the transom to install the transducer. Consider the following to find the best location:

∙ It is very important to locate the transducer in an area which is relatively free of turbulent water, As a boat moves through the water, turbulence is generated by the weight of the boat, and the thrust of the propeller(s). This turbulent water is normally confined to areas immediately aft of ribs, strakes or rows of rivets on the bottom of the boat, and in the immediate area of the propeller(s) (Figure 1). On outboard or inboard/outboard boats it is best to stay at least 15” (40cm) to the side of the propeller(s).

Читайте также:  Поплавочные эхолоты для рыбалки

∙ If possible, viewing the transom of the boat while the boat is moving will provide the best means of locating turbulence free water. If maximum high-speed operation is a high priority, this is the recommended method. If this is not possible, select a location on the transom where the hull forward of this location is smooth, flat, and free of protrusions or ribs.

∙ The transducer when mounted should point straight down. The design of the transducer will accommodate a wide range of deadrises and remain ported straight down (Figure 2).

∙ On boats with stepped hulls, it may be possible to mount the transducer on the step. Never mount the transducer on the transom behind a step, as this area of the transom will not be in contact with the water at high speed (Figure 3).

∙ If the propeller(s) is (are) forward of the transom, it may be impossible to find an area clear from turbulence, and a different mounting technique or transducer type should be considered.

Step Two — Drill the Mounting Holes

1. Remove the mounting template from the front of the Operations Manual.

2. Hold the template on the transom of the boat in the location where the transducer will be installed (Figure 4). Align the template vertically, ensuring the lower edge of the transom meets with the bottom corner of the template.

3. Using a pencil or punch, mark the two mounting holes shown on the template onto the transom. Do not mark or drill any other holes at this time.

4. Using a 5/32” (4mm) bit drill the two holes to a depth of approximately 1″ (3cm). On fiberglass hulls, it is best to start with a smaller bit and use progressively larger drill bits to reduce the chance of chipping or flaking the outer coating.

Step Three — Assemble the Transducer

1. Attach the Pivot to the transducer body as shown in Figure 5, using the #8 – 3/8” (9mm) long allen headed pivot screw, the headed pin, the two flat washers, and the two toothed lock washers.

Note: The toothed lock washers must be positioned between the transducer and the pivot ears. The flat washers must be positioned to the outside at the pivot ears.

2. Using the AIlen wrenches provided, loosely tighten the pivot screw (Figure 6). Do not completely tighten the assembly at this time, so the pivot angle can be adjusted later.

3. Insert the pivot/transducer assembly into the mounting bracket as shown in Figure 7. Do not snap the assembly closed.

Step Four — Mount the Transducer to the Transom

1. Apply silicone sealant to the mounting holes drilled into the transom.

2. Align the transducer assembly with the drilled holes in the transom (Figure 8).

3. Use either a flat head screwdriver, a 5/16″ (8mm) hex driver, or a 5/16″ (8mm) socket to mount the assembly. Using the two #10 – 1”

(25mm) long slotted hex head screws, mount the transducer assembly to the transom as shown. Do not fully tighten the mounting screws in order to vertically adjust the transducer. Snap the pivot down into place.

Step Five — Adjust the Running Position of the Transducer

The bracket allows height and tilt adjustment, the pivot screws allow angular adjustment. Initially, adjust the transducer as described in the following paragraphs. Further adjustment may be necessary to refine the instillation after high speed testing.

1. First adjust the pivot angle of the transducer body so its length is parallel with the length of hull of the boat. Then pivot the transducer down so the rear is about 1/4 inch (6mm) lower than the front (Figure 9).

2. Fully tighten the two pivot screws using the Allen wrenches. It may be necessary to retighten the pivot screws after the initial use as the plastics may still be seating to the lock washers.

3. Adjust the height of the assembly so the face of the transducer is 3/16″ (4.5mm) beneath the lower edge of the transom (Figure 10). Mark the position of the mounting bracket on the transom with a pencil.

4. Force the pivot to the up position to gain access to the mounting screws. Assure the transducer location has not changed, then fully tighten the two mounting screws (Figure 11). Snap the pivot back down.

Confirm the pivot angle has not changed.

Note: A third screw location is provided for the

mounting bracket. Drill this hole and install the screw after final testing and adjustments have been completed.

Step Six — Route the Cable

There are several ways to route the transducer cable to the to the area where the control head will be installed. The most common procedure routes the cable through the transom into the boat.

Inside the boat there is often a channel or conduit used for other wiring that the cable can be routed along. Do not cut or shorten the transducer cable and try not to damage the cable insulation. Route the cable as far as practical from the VHF radio antenna cables or tachometer cable to reduce the possibility of interference.

If the cable is too short, extension cables are available to extend the transducer cable up to a total of 50′ (15 m). Call Humminbird Customer Support for more information.

Follow these steps to route the cable through the transom:

1. Drill a 5/8” (16mm) hole above the water line. Route the cable through the hole.

2. Fill the hole with silicone sealant.

3. Place the escutcheon plate over the hole and attach with the two #8 x 5/8” (16mm) screws.

4. Secure the cable by attaching the cable camp to the transom using a #8 x 5/8” (16mm) screw.

Note: The transducer will pivot up to 90 degrees in the bracket. Allow enough slack in the cable for this movement. It is best to route the cable to the side of the transducer so the cable will not be damaged by the transducer during movement.
